World’s First Fully Corrosion-Resistant, Non-Metallic Magnetic Drive Submersible Pump
Works in strong acid and alkalis. A built-in thermal protector, lightweight construction and easy handling for emergency situations.
Features
- Submersible carbon pump and carbon fiber-coated stainless screws resistant to acid and alkaline liquid
- Built-in thermal protector with automatic motor shutoff system to prevent breakdown
- Magnetic drive system with no liquid penetration into the motor
- A grip (handle) attached for easy transfer at a time of an emergency
- No mechanical seals = no lubricant = safe to transfer liquid chemical
- Operates in high-temperature environment (up to 70℃/158℉)
Applications
- Pumping water from underground pits or tanks
- Drawing liquid out of liquid freezing tanks or bottom of containers
- Circulating/stirring liquid in tanks
- Transferring liquid
- Pickling
Example of use
Features
Spec
Example of use
- Lowest suction point of only 10mm(0.4in)
- Transfers even foamy chemicals.
- Durable in environments where surface layers are frozen.
- Pumps waste water from holding tank.
- To Pump up from breakwater / broiler room.
Features
- Corrosion Resistant(Carbon Fiber Reinforced Polypropylene)
- Capable of performing 15GPM/19TDH(1in. Bore)
- Magnetic-Drive Submersible pump means no mechanical seals or lubrication oils!
- Max Temp: 104, Insulation Class F.
Spec
| Hz | S.G. | Hose size | Standard specification | Motor | Liquid temp. | Weight | ||||
| T.H,D. | Capacity | Output | Voltage/ph | Insulation | ||||||
| YD-25A6WN-CP-RD52 | 50Hz | 1.2 | Inner diameter:1″ (25mm)Outer diameter:1.3 (33mm) | 19ft (6m) | 15gpm (60L/min) | 1/3HP (0.26kW) | 115V 1 Phase | F | 104F Max | 30 lbs (14kg) |
| YD-25A6GWN-CP-RD61 | 60Hz | 1.2 | ||||||||
