Circulating Pump with Superb Heat and Chemical Resistance
Seal-less construction resistant to heat and chemicals. This pump reduces air entrapment and improves suction performance. Long-lasting with the structure that protects the motor from corrosion due to the gas from chemicals.
Features
- Construction with NO mechanical seal and bearings
- Resistant to wide range of chemicals and high temperatures (temperature range: 0 – 85℃/32 – 185℉)
- Replaceable cantilevered sleeved stainless-steel shaft
- Reduces air entrapment for improved chemical suction performance
- Extremely durable, easy to maintain
- Structure with integrated suction and discharge sides allows NO leak
- Loose flange for easy setup
Applications
- Etching
- Circulating chemical inside/outside of the tank
- Scrubber systems (washing tower)
- Mixing chemicals to even out the chemical concentration
YD-AVK Performance Curve
YD-AVP Performance Curve
Example of use
Model
Features
Example of use
- Etching
- Circulating pump for scrubber (washing tower) system
- Circulating/transferring pump for chemical reaction and mixing tanks
- Circulating/stirring pump for electroless nickel plating solution, general plating solution, filters, heat exchangers, etc.
- Transferring pump for emptying and replacing chemicals
- Specific gravity 1.1. It can be used in/out of a tank. Perfect for circulating pump for scrubber system.
- Specific gravity 1.4. High pressure pump. For printed circuit boards and etching machines.
Model
- YD-4001VK (1HP)
- YD-4002VK (2HP)
- YD-4003VK (3HP)
- YD-5005VK/VP (5HP)
- YD-6507VK/VP (7.5HP)
- YD-6510VK/VP (10HP)
Features
- Gas Seal Mechanism
- Sealless construction
- Resistance to Chemicals
- Resistance to heat (Possible temperature range: 32F to 185F)
- Bearing -less
- Replaceable cantilevered sleeved stainless steel shaft
- Reducing air entrapment and improving suction performance
